16L Obstacle Avoidance Drone Agriculture Purpose 16kg Atomizing Sprayer Drone For Weed At Low Cost
Save -49%
Rs. 1,002,575.80
Rs. 1,983,820.20
Share
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Security
FREE SHIPPING
WORLDWIDE
BIG SAVING ON
WEEKENDS
24H SUPPORT
CONTACT US
UAV Sprayers carbon fiber frame kit 16 Kgs Crop Sprayer Drone accessories for AG Drone Crop spraying drones
The Details of sprayer drones
Model
|
|
JT10L-404QC
|
JT16L-404QC
|
|
Pesticide Tank
|
|
10L
|
16L
|
|
Net Weight
|
|
13kg
|
18kg
|
|
Take-off Weight
|
|
27kg
|
40kg
|
|
Flying Time
|
|
10~15min
|
10~15min
|
|
Flying Radius
|
|
0~1000m
|
0~1000m
|
|
Flying Height
|
|
0~30m
|
0~30m
|
|
Flying Speed
|
|
0~12m/s
|
0~12m/s
|
|
Work Temperature
|
|
-10~70°C
|
-10~70°C
|
|
Work Humidity
|
|
0~90%
|
0~90%
|
|
Spray Speed
|
|
0~8m/s
|
0~8m/s
|
|
Spray Width/Nozzle No.
|
|
>3.5~5.5m / 4 Nozzles
|
>4~6m / 8 Nozzles
|
|
Spray Flow
|
|
1~1.5L/min
|
2~2.5L/min
|
|
Spray Efficiency
|
|
5~7Ha/Hr
|
8~10Ha/Hr
|
|
Flying Downward Airflow
|
|
4~15m/s
|
4~15m/s
|
|
Wind Resistance
|
|
10m/s
|
10m/s
|
|
|
Spread Size
|
W1.14m x L1.12m x H0.58m
|
W1.40m x L1.35m x H0.7m
|
|
Folded Size
|
W0.82m x L0.64m x H0.58m
|
W0.88m x L0.77m x H0.7m
|
||
|
Motor
|
Brushless
|
Brushless
|
|
Propeller
|
Carbon Fiber
|
Carbon Fiber
|
||
ESC
|
Rapid Throttle Response
|
Rapid Throttle Response
|
||
Flight Control
|
|
K++ V2
|
K++ V2
|
|
Remote Controller
|
|
Joyance Datalink H12 RC
|
Joyance Datalink H12 RC
|
|
Battery / Quantity
|
|
14S 10000mAh / 1pc
|
14S 20000mAh / 1pc
|
|
Adapter + Charger
|
|
Dual-Channel Charger 2400W
|
Dual-Channel Charger 3000W
|
|
Aluminum box size / weight
|
|
8*92*68cm / 50kg
|
98*92*75cm / 65kg
|
|
Toolkit
|
|
Maintenance/Repair Tools
|
Maintenance/Repair Tools
|
Joyance Tech provides OEM/ODM services for agriculture drones.
Advantages of agriculture sprayer drones
2. Fashionable and Exclusive appearance, the waterproof of whole drone is IP56, sprayer drone is suitable for working in the rain.
3. The front-end control system and the back-end power supply system are independent, reasonable wiring, avoid electromagnetic interference, also easy to repair and replace.
4. Nozzle and Spray boom (1) High pressure nozzle: spray width: 4-6m; Less drift; has automatic relief valve. No miss spray or re-spray; Good spraying effect. (2) Spray boom: soft connection designed, not easy to damage.
5. Two brushless water pumps for 30L drone sprayer. Brushless water pumps can be used for more than 500 hours, which are 3-5 times longer than ordinary water pumps , this is will reduce maintenance cost. Voltage range: 12-14V Max flow: 2 * 5L/min Waterproof: IP 68 After finishing spraying, it can be washed with water directly to reduce pesticide corrosion.
6. Joyance agriculture sprayer drone with granule spreader can spread solid fertilizers/ granule fertilizer, seeds, sows, feed and so on.
