Sale

Factory Price Radiolink Balance Charger CB86 Plus for 8pcs 2-6S Lipo Battery With Jst Connector at Professional For RC Toys

Write a review

Save -54% Rs. 32,417.65 ~~Rs. 70,737.40~~

Brand : Shanvis

Collection : Beauty & Personal Care Lipstick- Lipcare

SKU : 5861596013089_434325322

Availability : 199 In Stock Sold Out 199

HURRY ! ONLY 199 LEFT IN STOCK.

Color Black

Socket Standard SV terminal

Translation missing: en.products.product.product_variants

Quantity

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Security

FREE SHIPPING

WORLDWIDE

BIG SAVING ON

WEEKENDS

24H SUPPORT

Description
Shipping

CB86 PLUS Charger Specifications

Input Voltage	DC10.5V-15V
Max.Output Power	156W
Charging Current	0.3-6.0A
Discharging Current	1.2A(fixed)
Charging Voltage	0.00V-4.23V
Setting Precision	0.01V
Balance Current	0.3~6A
Supporting Battery	1S~6S LiPo battery (4.2V), 1S~6S Li-ion battery (8 ports available), or 1S~6S High voltage lithium battery (4.35V)
Working Modes	Cycle/Discharge/Storage
Screen	2.8” TFT screen
Sound Notification	Buzzer, customizable
Size	18810457mm (7.4” 4.09” 2.24”)
Weight	0.8kg(1.76lb)

1mV Precision

The precision of 0.001V, 10 times precise than the competing product of 0.01V.

Upgrade with USB

With a USB cable (of data transmission) connect to the computer, the latest firmware of CB86-PLUS can be easily copied or deleted without any extra device.

Guaranteed Protection

Pulse current charge mode, software optimization and circuit design optimization of new version CB86-PLUS reduced the wastage of electron device, improves the service life and achieve better battery protection. Statistical analysis of charging trend by software, new version CB86-PLUS can detect the hardware failure timely and then stop charging immediately. CB86-PLUS is developed as polarity control which ensures protection to both the charger itself and the battery when there’s reverse polarity connection and can automatically stop function if the input voltage is over(>15V) or less (<10.5V). When CB86-PLUS is powered off, charging battery won’t be discharged and can be well protected. Even any charging battery is accidentally pulled off, CB86-PLUS will self-protect to reduce the risk of getting damaged caused by sudden voltage increase at the charging port.

Power Supply Self-adapting

If the maximum power output of power supply cannot meet the charging power,the current will reduce automatically to adapt to the maximum output of the power supply.

Power smoothing method solve the problem that some power supply cannot start rated power instantaneously.

Charging in Turn, Safer

With the patented port (No. 201320212324), CB86-PLUS is compatible with battery of 1S~6S.

It can identify all charging ports by setting only one time to automatically charges the battery that are not yet fully charged and avoid the low efficiency and the damage risk because of the possible various resistance of each cell.

Charging Voltage and Current Set Separately

Different from the old version CB86-PLUS, the new version CB86-PLUS with V2.5 firmware make charging voltage and current set separately for each charging port come true. Eight charging port totally, very friendly for different capacity batteries charging at the same time.

135mA Work Current
Always Less Than 35 Degree

Power management adopts a switch circuit with the most efficient individual PUSH-PULL design for each charging cell. The operating current of CB86-PLUS is as low as 135mA and the charging efficiency up to 97%. Soft-Switching technology reduced the wastage of switch, the temperature of CB86-PLUS remains 35°C no matter it is on standby mode or fully working model.

Tremendous Advantages of CB86-Plus Charger

1. Better charger to charge, service, repair and store the lipo batteries!
2. Keep all your inventory of batteries healthy!

Battery Doctor

CB86-PLUS can calculate battery resistance parameters, recording battery performance such as initial voltage, finished voltage, charge voltage, and discharge voltage. Battery repair function make the battery which discharge to lower than 3.0V regain capacity.

Multiple Input

The input power supply can be a 3S LiPo battery or a DC power source of output voltage 10.5-15V and current more than 15A.

Real-Time Display

The charging status of each cell can be checked on the display of the charger. When one cell of the battery has fully charged, a green cursor will indicate the charging status in addition to the beeping sound. Real Time Operating System (RTOS) makes the function buttons response and parameter menu switch refresh without delay.
