Diesel Mini Skid Steer Loader with CE EPA China Sale Yellow Red Orange Blue Customized Long Power Engine Track Pump Technical
Save -55%
Rs. 2,567,881.43
Rs. 5,754,018.03
HURRY ! ONLY
1000 LEFT IN STOCK.
Share
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Security
FREE SHIPPING
WORLDWIDE
BIG SAVING ON
WEEKENDS
24H SUPPORT
CONTACT US
Product Description
Title goes here.
Diesel Mini Skid Steer Loader with CE EPA China Sale Yellow Red Orange Blue Customized Long Power Engine Track Pump Technical
Specification
|
HONDA HGX690
|
Briggs Stratton 3864
|
Rato R740
|
|
|
Lifting Capacity KG
|
350
|
380
|
380
|
|
Engine Type
|
HONDA HGX690
|
Briggs Stratton 3864
|
Rato R740
|
|
Engine Capacity（kw/Hp)
|
16.5/22.1
|
18.2/23
|
15.5KW
|
|
Displacement cm3/Number of cylinders
|
688/2
|
670/2
|
|
|
Rotation speed per minute（rpm)
|
3600
|
3600
|
3600
|
|
Maximum torque NM/rpm
|
38.6/2500
|
50/3000
|
45/2500
|
|
Cooling method
|
Air-cooled
|
Air-cooled
|
Air-cooled
|
|
Fuel/Fuel tank capacity
|
Gasoline 95#/20L
|
Gasoline 95#/20L
|
Gasoline 95#/20L
|
|
Drive System
|
Hydraulic four-wheel drive
|
Hydraulic four-wheel drive
|
Hydraulic four-wheel drive
|
|
Speed（km/h)
|
0-5.5(By Scale）
|
0-5.5(By Scale）
|
0-5.5(By Scale）
|
|
Enhancement of capabilities（kg)
|
350
|
300
|
300
|
|
Traction force（kg）
|
409
|
||
|
Hydraulic drive system（L/bar)
|
35/200
|
50/180
|
50/180
|
|
Hydraulic oil tank capacity（L）
|
40
|
35
|
35
|
|
Standard Tires
|
22*11.00-8
|
18*8.5-8
|
18*8.5-8
|
|
Electrical system（V）
|
12
|
12
|
12
|
|
Battery Capacity（Ah)
|
45
|
36
|
36
|
|
Braking System
|
Hydraulic enclosed brake
|
Hydraulic enclosed brake
|
Hydraulic enclosed brake
|
|
Drive
|
Skid steering
|
Skid steering
|
Skid steering
|
|
Hydraulic Cylinder Thrust（KG）
|
600
|
||
|
Rising Force（KG）
|
300
|
||
|
Overall Dimensions（MM）
|
1525*1050*1258
|
1485*1150*1300
|
1485*1150*1300
|
|
Weight（KG）
|
630
|
830
|
830
|
