5.5KW 24V 48V MPPT Support With WiFI High Frequency Solar Controller built-in 100A Hybrid Solar Inverter
Save -56%
Rs. 171,586.76
Rs. 392,198.30
HURRY ! ONLY
9999 LEFT IN STOCK.
Share
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Security

FREE SHIPPING
WORLDWIDE

BIG SAVING ON
WEEKENDS

24H SUPPORT
CONTACT US
SH tech 3kw 5kw hybrid solar inverter with wifi ready for ship
One stop service, online customization, fast delivery, sample available. drop shipping
Products Description

Rated Power
|
3500VA/3500W
|
5500VA/5500W
|
|
Voltage
|
230VAC
|
||
Selectable Voltage Range
|
170~280VAC(For Personal Computers)
|
||
90~280VAC(For Home Appliances)
|
|||
Frequency Range
|
50Hz/60Hz(Auto sensing)
|
||
AC Voltage Regulation(Batt.Mode)
|
230VAC±5%
|
||
Surge Power
|
7000VA
|
11000VA
|
|
Efficienc(Peak)PV to INV
|
97%
|
||
Efficienc(Peak)Battery to INV
|
94%
|
||
Transfer Time
|
10ms(For Pensonal Computers);20ms(For Home Appliances
|
||
Battery & AC Charger
|
|||
Battery Voltage
|
24VDC
|
48VDC
|
|
Floating Charge Voltage
|
27VDC
|
54VDC
|
|
Overcharge Protection
|
33VDC
|
63VDC
|
|
Maximum Charge Current
|
80A
|
80A
|
|
Maximum PV Array Power
|
5000W
|
6000W
|
|
MPPT Range @ Operating Voltage
|
120~450VDC
|
||
Maximum PV Array Open Circuit Voltage
|
500VDC
|
||
Maximum Charging Current
|
100A
|
100A
|
|
Maximum Efficiency
|
98%
|
||
Dimension,D*W*H(mm)
|
100*300*440
|
||
Net Weight(kgs)
|
11
|
12
|
|
Communication Interface
|
USB/RS232/GPRS/WIFI
|
||
Mumidity
|
5% to 95% Relative Humidity(Non~condensing)
|
||
Operating Temperature
|
0℃~55℃
|
Details Images
