42MM 0.1NM IE 2 NEMA17 6000rpm Stepper Motor 24V 60W BLDC Motor Tubular Motor
Save -44%
Rs. 21,490.93
Rs. 38,668.18
HURRY ! ONLY
9999 LEFT IN STOCK.
Share
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Security
FREE SHIPPING
WORLDWIDE
BIG SAVING ON
WEEKENDS
24H SUPPORT
CONTACT US
Product Details
NEMA17 12V 24V brushless BLDC motor 42MM IE 2
Tubular Stepper motor brushless4000rpm 6000rpm
Smooth lines
Delicate appearance
High quality material
Resistance to wear and tear
Adapt to work environment with special needs
Parameters
|
Item
|
Specifications
|
|
Winding type
|
Star/Delta
|
|
Hall effect angle
|
120°
|
|
Shaft runout
|
0.025mm
|
|
Radial play
|
0.02mm/450g
|
|
End play
|
0.8mm/450g
|
|
Max radial force
|
28N/20mm from the flange
|
|
Max axial force
|
10N
|
|
Insulation class
|
Class B
|
|
IP class
|
IP 40
|
|
Dielectric strength
|
500VDC for one minute
|
|
Insulation resistance
|
100MΩmin 500VDC
|
|
Model NO.
|
Rated Voltage
|
Rated Current
|
Rated Power
|
Rated Torque
|
Peak Torque
|
Rated Speed
|
Length
|
Mass
|
|
42BLY40-140
|
12v
|
1.1A
|
10w
|
0.024nm
|
0.072nm
|
4000rpm
|
40mm
|
0.2kg
|
|
42BLY60-150
|
12v
|
1.6A
|
15w
|
0.029nm
|
0.087nm
|
5000rpm
|
60mm
|
0.3kg
|
|
42BLY80-150
|
12v
|
2.7A
|
25w
|
0.048nm
|
0.144nm
|
5000rpm
|
80mm
|
0.4kg
|
|
42BLY40-250
|
24v
|
1.1A
|
20w
|
0.038nm
|
0.114nm
|
5000rpm
|
40mm
|
0.2kg
|
|
42BLY60-260
|
24v
|
1.6A
|
30w
|
0.048nm
|
0.144nm
|
6000rpm
|
60mm
|
0.3kg
|
|
42BLY80-260
|
24v
|
3.3A
|
60w
|
0.096nm
|
0.288nm
|
6000rpm
|
80mm
|
0.4kg
|
